Mechatronic make Impact Testing Machine Model M – IT30 is designed for conducting Izod &Charpy Test. The test methods confirm to BS : 131 : PART 4 – 1972 (Amended 15 Aug. 1993) & BSEN : 10045-2 : 1993 The Pendulum is mounted on antifriction bearings.
Model: M IT30E
Brand: Mechatronic
Applications: Hardness Testing
Industries: Aerospace, Automotive, Electronics, Inks and Coatings, Metal Packaging
Materials: Aluminum, Steel
Control of Pendulum:
The Pendulum supporting in the starting positions is by a self resetting latch. The release mechanism is operated by lever. The Pendulum release latch is operated only when this lever is operated.
Strikers & Supporters:
There are strikers & one combined support available for fitting into the Pendulum & on to the base of the machine for Izod, Charpy test. Changing from one striker to another is achieved simply by fixing the new
Charpy Test:
The Charpy test piece rests on alloy steel supports anvils fitting on the base of the machine rigidly held in position by allen screws. End stopper is provided for quickly & accurately location the test piece centrally between the supports.
Izod Test:
The Izod test piece is clamped vertically in Izod support anvils, fitted on the base of the machine. The support is provided with a machined vertical groove to suit the test piece size. The front clamp piece & allen screw enable clamping of the piece in correct height with the help of Izod setting gauge supplied.
| SPECIFICATION | M – IT 30 | M – IT 30 E |
|---|---|---|
| Maximum Capacity | 300 J / 168 J | 300 J / 170 J |
| Minimum Scale Graduation | 2 J | 0.5 J |
| Overall Size (Approx.) | 1.65 m (H) | 1.65 m x 0.45 mx |
| 1.1 m x 045 mx | 1.65 m (H) | |
| Net Weight (Approx.) | 375 Kg. | 375 Kg. |
- Caliper gauge for checking V notch for Izod & Charpy as per BS : 131 : PART 1, 2, 3
- Depth notch gauge including V & U notch, angle & radius.
- Self centering tong.
- V – notch milling cutter.
- U – notch milling cutter.
